Double-disc Ditching Machine

Main Function & Application

The double-disc ditching machine is a professional farmland trenching implement suitable for ditches and drainage ditches. It is used for digging agricultural water channels, field ditches, irrigation ditches, drainage ditches and other linear ditch operations. The double-disc design makes the ditch shape neat, the trench bottom stable, and the soil separation effect good. It can be used for farmland water conservancy construction, orchard ditch digging, vegetable field ditch digging and other agricultural engineering operations.

Product Parameters

Style No: 1KS-35

 Overall Dimensions: 162×84×120 cm

 Weight: 390 kgs

 Matching Power: 70–130 HP

 Trench Bottom Width: 16/20 cm

 Trench Top Width: 35–45 cm

  Trench Depth: 30–35 cm

 Number of Straight Blades: 24 pcs

 Number of Curved Blades: 6 pcs
